Engineered for critical structures, the Rifeng W series delivers superior modulus and thermal resistance. It serves as the backbone for aerospace fuselages, wind turbine blades, and high-speed rail components where weight reduction is mandatory.

What defines the Rifeng W Series?

The Rifeng W Series is a structural rigid foam based on Polymeric Methylmethacrylate (PMI). It features a 100% closed-cell structure, ensuring minimal resin uptake during composite processing.

Designed for industrial composite applications, it withstands curing temperatures up to 180°C (356°F) and pressures used in autoclave and RTM technologies. This makes it a standard-compliant core material for aviation interior panels, radar domes (Radomes), and medical X-ray tables.

Aerospace & Structural Application

Rifeng PMI Foam used in Aerospace Structure

Figure 1: Rifeng W core applied in complex curvature aerospace components, demonstrating thermoforming capabilities.

Performance Parameters

Property	Specification
Core Material	Rigid PMI Foam
Cell Structure	Closed-cell / Isotropic
Thermal Distortion	> 180°C
Dielectric Constant	~1.05 (at 2-18 GHz)

Radome Compatibility: Near-air dielectric properties ensure zero signal interference for antennas.

Process Ready: Compatible with prepreg curing and vacuum infusion without core collapse.

Need density charts? View the Full Rifeng PMI Collection.

Industrial Feedback

"The pore size consistency of Rifeng W is crucial for our drone wing manufacturing. We achieved a 15% weight reduction compared to PVC cores."

UAV Structural Engineer

Shenzhen, China

"We utilize Rifeng W for high-speed rail interior panels. It meets our strict FST (Fire, Smoke, Toxicity) requirements and bonds well with phenolic resins."

Procurement Director

Berlin, Germany

"Supply chain stability was our main concern. Rifeng has consistently delivered large-format sheets for our wind blade prototypes on time."

Project Manager

Wind Energy Sector

Technical & Ordering FAQ

What is the heat distortion temperature of Rifeng W?

Rifeng W series maintains structural integrity up to 180°C - 220°C depending on the specific grade, making it suitable for aerospace autoclave cycles.

Can Rifeng W be thermoformed?

Yes. Due to its thermoplastic nature, Rifeng PMI foam can be thermoformed into complex geometries (like curved fuselage panels) by heating it to approximately 205°C.
